Custom Swiss Turning Parts with ±0.002~0.005mm Tolerance, ISO9001 Certified and 100% Inspection for Medical Applications
| Place of Origin | China |
|---|---|
| Brand Name | IMission |
| Certification | ISO9001 |
| Model Number | CNC Turning |
| Minimum Order Quantity | I PC |
| Price | 0.1~5USD |
| Packaging Details | Bubble and Carton or Customization |
| Delivery Time | 7~35 working days |
| Payment Terms | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability | 10000pcs per month |
Product Details
| Material | Aluminum | Weight | 0.1-8kg |
|---|---|---|---|
| Service | OEM Or ODM | Key Word | CNC Turning Parts |
| Shipping Method | Express, Air, Sea, Etc. | Product Process | CNC Turning |
| Quality | 100% Inspection | Our Service | 24 Hours Online |
| Feature | Durable And High Precision | Surface Finishing | Anodizing, Plating, Polishing, Etc |
| Processing | CNC Machining, CNC Milling, CNC Turning,Stamping... | Drawing | IGES(igs), STEP(stp), SolidWorks (sodprt), PRT, AutoCad,PDF Or Samples |
| Highlight | ISO9001 Certified CNC Milling Parts，100% Inspection CNC Machined Parts | ||
| Highlight | ±0.002~0.005mm Tolerance CNC Turning Parts,ISO9001 Certified Swiss Turning Parts,100% Inspection Precision Machined Components |
||
Product Description
Custom Swiss Turning Service for Medical Parts
Our precision CNC turning service specializes in manufacturing high-quality medical components with exceptional accuracy and consistency. We deliver custom Swiss-turned parts that meet the stringent requirements of the medical industry.
CNC Turning Parts Specifications
| Product Name | CNC Turning Parts |
|---|---|
| Material Available | Aluminum |
| Processing | CNC Turning |
| Tolerance | ±0.002~0.005mm |
| Drawing Accepted | IGES(igs), STEP(stp), SolidWorks (sodprt), PRT, AutoCad, or Samples |
| Inspection | CMM, Projector, Height Gauge, etc. |
| Lead Time | 7~35 working days |
| Quality Assurance | ISO9001:2015, SGS, RoHs |
| Payment Term | MoneyGram, Western Union, T/T, D/P, D/A, L/C |
| Price | According to your drawing or requirements |
Packaging and Delivery
| Packaging | Bubble and Carton or Customization |
|---|---|
| Port | Shenzhen |
CNC Turning Capabilities
Our CNC turning parts deliver exceptional precision and consistency, capable of machining metal and non-metal components with complex structures including shafts and discs. Controlled by pre-set programs, our process enables one-time forming of intricate details such as complex threads, chamfers, and grooves, making these parts ideal for demanding applications across multiple industries.
Manufacturing Capabilities & Specifications
A. Equipment Specifications
| Machine Type | Axis Configuration | Maximum Dimensions | Tolerance Capability | Special Features |
|---|---|---|---|---|
| Swiss-Type Lathes | 5-13 axis | Ø32mm * 300mm | ±0.005mm | Simultaneous machining, live tooling, backworking |
| Multi-Axis Turning Centers | 6-9 axis | Ø250mm * 500mm | ±0.01mm | B-axis milling, Y-axis capability, sub-spindle |
| CNC Lathes | 2-4 axis | Ø600mm * 1000mm | ±0.02mm | Hydraulic chucking, bar feeders, part catchers |
| Turn-Mill Centers | 7+ axis | Ø150mm * 400mm | ±0.008mm | Complete part processing in single setup |
B. Technical Parameters
Standard Tolerance Range: ±0.01mm to ±0.05mm
Fine Tolerance Capability: ±0.005mm (for critical dimensions)
Surface Finish: Ra 0.4μm to Ra 3.2μm (standard)
Ultra-Finish Options: Ra 0.1μm achievable with polishing/burnishing
Geometric Tolerances:
- Concentricity: 0.005mm
- Cylindricity: 0.008mm
- True Position: 0.01mm
Thread Machining Capabilities:
- Metric/Unified/Whitworth threads
- ACME, trapezoidal, and special forms
- Single-point threading up to 64 TPI
- Thread rolling capabilities
Material Expertise
A. Metals & Alloys
| Material Category | Specific Grades | Machinability Rating | Typical Applications |
|---|---|---|---|
| Aluminum Alloys | 6061, 7075, 2024, 5083 | Excellent | Aerospace, automotive, electronics |
| Stainless Steels | 303, 304, 316, 17-4PH, 416 | Good to Fair | Medical, marine, chemical processing |
| Carbon & Alloy Steels | 1018, 1045, 4140, 4340 | Excellent | Industrial machinery, automotive |
| Tool Steels | D2, A2, O1, S7 | Fair to Difficult | Molds, dies, tooling components |
| Copper Alloys | C360, C464, C17200, C10100 | Excellent | Electrical, plumbing, marine |
| Exotic Alloys | Titanium (Gr2, Gr5), Inconel, Monel | Difficult | Aerospace, medical implants |
| Magnesium Alloys | AZ31B, AZ91D | Excellent (with precautions) | Aerospace, portable devices |
B. Non-Metallic Materials
Engineering Plastics: PEEK, Delrin/Acetal, Nylon, PTFE, POM
Composites: Carbon fiber reinforced, fiberglass composites
Special Materials: Ceramics (machinable grades), graphite, engineered woods
Full-Scale Services
We provide a complete solution, offering secondary operations including milling, drilling, threading, knurling, alongside finishing services like anodizing, plating, passivation, heat treatment, and powder coating.
Industries We Serve
Automotive
Aerospace
Medical & Dental
Electronics & Industrial
Our Product Portfolio
We manufacture a diverse array of turned components, including:
Shafts & Pins
Precision shafts, axles, dowel pins, and studs
Fasteners & Connectors
Specialized bolts, screws, standoffs, spacers, bushings, and couplings
Complex Fittings
Hydraulic and pneumatic fittings, nozzles, and valve components
Custom Components
Any custom-designed part based on your technical drawings or samples
Why Partner With Us?
Uncompromising Quality
Rigorous inspection using advanced measuring equipment ensures every part meets exact specifications
Technical Collaboration
Expert DFM feedback to optimize your part for performance, cost, and lead time
Supply Chain Reliability
Consistent on-time delivery with flexible production planning
Competitive Value
Optimized processes and economies of scale maximize your ROI
Confidentiality & IP Protection
Your designs handled with utmost security and professionalism
Your Trusted Manufacturing Solution
Whether you need a small batch of prototype parts or sustained, high-volume production supply, we are equipped to be your seamless extension. We specialize in OEM & ODM manufacturing, ready to work from your drawings or collaborate on custom designs.
Contact Us Today to request a competitive quotation, discuss your project specifications, or learn more about how our precision CNC turning services can enhance your supply chain.
